Underground Car Lift Device
video
Underground Car Lift Device

Underground Car Lift Device

Underground Car Lift device L4800 Main unit Underground. Support Arm on the Ground

1. Introductions

Good Man-Machine Environment, efficient and convenient operating

Mechanical and hydraulic safety device. Ensure the safety of people and vehicle.

2.Technical data

Lifting capacity: 3500kg

Max lifting height: 1850mm

Full lifting/Lower time: 40/60 sec

Main unit Legth: 1700mm

Main unit Width: 415mm

Main unit height: 2515mm

3.Advantages

◆ Equipped with automatic cover plate mechanism, workshop clean and tidy (optional)

◆ Separate design, applicable to complicated Geological and working condition (Optional)

◆ Special synchronization and quadratic

◆ Dimension between two posts: 2350mm

4. Packing and delivery

Packing & Delivery
